Solar Cable

solar cable,16.0mm2

【Produce Description】

Name：16.0mm2 single core solar cable

●Cross Section: 16.0mm2

●Rated Current: 132A

●Core: NO. 1

●Conductor Construction: NO./mm 128/0.4

●Conductor Stranded OD.：4.5mm

●Insulation min thickness ：1.42mm

●Sheath min thickness：1.42mm

●Cable OD. ：10.2±0.1mm

●Conductor Resistance（20℃）：≤1.21 Ω/km

●Test Voltage kV/min： 6.5/5 No breakdown

●Rated Temperature: -40~﹢90℃

●Conductor Max Temperature: ﹢120℃

●Reference short circuit permissible temperature：200℃5S

●Guarantee time:＞25年（ -40~﹢90℃）

●Rated Voltage: DC:1.8kv AC U。/U: 0.6/1kv

●Working environment temperature ℃： -40~﹢90

●Work Voltage AC/DC（KV）： 0.6~1.0/1.8

●Climate resistance: UV

●Flame retardant: single vertical combustion (IEC60332-1)

●Sunlight resistant：HD605/A1

●Ozone resistance test of finished cable：EN50396

●Smoke：IEC61034，EN50268-2

●Halogen acid release：IEC670754-1 EN50267-2-1

Model:	Solar Cable16.0mm2	Price:	USD 1.65/meter
Minorder:	1000 meters	Supplyability:	100000meters/month
Payment:	T/T payment	Port:	Ningbo port
Certification:	CE,CCC,TUV,UL	Brand:	Leables
Place:	Jiaxing City,Zhejiang Pro,China	Packaging:	according to the request

Zhejiang Lizhou Wire And Cable Co., Ltd., founded in 1991, is a modern high-tech enterprise, integrating R&D, production and sales as one, specializing in wire & cable and related products,which include electrical wire, power cable, control cable, silicone wire, power plug, wire harness, LED connecting wire, and other series varieties.

With more than 20 years rapid development, the company become one of the industrial leaders, which covers an area of 50000 square meters, fixed assets of 70 million, annual production capacity of more than 500 million yuan.

The company has 180 outstanding employees, a complete set of advanced equipments in production and QC, first-class working environment, and efficient management system.

Lizhou get through CCC certification and ISO9001:2008 certification, really reaching multinational company’s management level. Lizhou Cable, with unique quality pursuit and dedication spirit, combined with advanced production technology, , has won high reputation in mainland China. Nowadays Lizhou Cable expand the sales in overseas market like Europe, the United States, Southeast Asia, Middle East,etc.

To meet the customers needs well and to lead the cable industry innovation trend will be Lizhou’s constant pursuits.
